Product Features

• Built-in variable electronic crossover features 12dB per octave so system tuning is optimized based on speaker location and accompanying loudspeaker components.
• GTO1004 ensures optimum power delivery into numerous impedances with low distortion.
• Full-range preamp outputs facilitate multiple amplifier hook-ups without the need for high-loss Y-adapters or signal splitters.
• Direct-connect allows up to 4-guage power and ground cable to ensure maximum power is delivered.
• Direct-connect speaker terminals eliminate the need for additional adapters or special fittings.

Specifications:

• # Of Channels

4

• 1 OHM Output Power - Full Range

Not Applicable

• 14.4V Dynamic Power At 2 Ohms

Not Applicable

• 2 Ohm Output Power - Full Range

600W

• 4 Ohm Output Power - Full Range

400W

• Bass Boost

Variable

• Bridgeable

Yes

• Bridged Power At 2 OHMS - Full Range

Not Applicable

• Bridged Power At 4 OHMS - Full Range

Not Applicable

• External Bass Control Capable

Yes

• Fuse Rating (Amps)

3 x 25 Amps

• High Pass Filter

No

• Included In Box

User Guide, Screws, Spare Fuses

• Input Voltage

12V

• Low Pass Filter

Variable

• Mosfet Switching

No

• Overload Protection

Yes

• Product Dimensions

26.4(W) x 5.4(H) x 47.2(D) cm

• Product Weight

6.6 kg

• Protection Indicator

Yes

• RCA Inputs (Pairs)

4

• RCA Outputs (Pairs)

4

• Screw Type Terminals

Yes

• Signal To Noise Ratio

104dB

• Smart Engage Turn-On

Yes

• Speaker LVL Inputs

Yes

• Total Max Power

660W

• Tri-Mode Capable

No

• Warranty Labour

1 Year(s)

• Warranty Parts

1 Year(s)
