Engenius EAP-3660 108Mbps Universal Repeater INDOOR AP

802.11g High Power 600mW Wireless Access Point / Universal Repeater with Smoke Detector Design & 802.3af PoE

EAP-3660 offers a "smoke detector" look, and is a high-powered wireless access point / universal repeater that operates seamlessly in the 2.4GHz frequency spectrum supporting 802.11b (2.4GHz, 11Mbps) standard and SuperG 108Mbps high speed feature. It is the best way to add long range wireless capability to your existing wired network or to add bandwidth to your wireless installation.

EAP-3660 features high wireless output power and receive sensitivity along with antenna diversity. High output power and high sensitivity extend wireless coverage to reduce the roaming between access points and to provide a reliable wireless connection. It also reduces the total cost of ownership on hardware.

To protect your wireless connectivity, it can encrypt all wireless transmissions through 64/128bits WEP data encryption and also supports WPA/WPA2. The MAC address filtering lets you select exactly which stations should have access to your network. In addition, the user isolation function can protect the private network between client users.

The attractive design, high performance and array of features make the EAP-3660 a suitable wireless solution for your residence or office.

Basic Info

User Type	Business
Technology	10/100 • Wireless G
Application	Super Long Range • Indoor
Model Number	EAP-3660

HARDWARE SPECIFICATIONS:
MCU: Atheros AR2316, 180MHz
Memory: 16MB SDRAM
Flash: 4MB
Physical Interface:
LAN One 10/100 Fast Ethernet RJ-45
Reset Button
Power Jack
LEDs Status:
Power (Status)
LAN (10/100Mbps)
WLAN (Wireless Connection)
Power Requirements:
Power Supply: 90 to 240VDC ± 10%, 50/60Hz (Depends on different countries)
Active Ethernet: (Power-over-Ethernet, IEEE 802.3af) 48VDC/0.375A
Device: 12V/1A
Regulation Certifications: FCC Part 15, ETSI 300/328/CE

RF SPECIFICATIONS:
Frequency Band: 2.400~2.484GHz
Media Access Protocol: Carrier Sense Multiple Access with Collision Avoidance (CSMA/CA)
Modulation Technology :OFDM: BPSK, QPSK, 16-QAM, 64-QAM, DBPSK, DQPSK, CCK
Operating Channels: 11 for North America
Receive Sensitivity (Typical):
IEEE 802.11g
6Mbps @ -92dBm
54Mbps @ -74dBm
IEEE 802.11b
1Mbps @ -97dBm
11Mbps @ -89dBm
Available Transmit Power:
IEEE 802.11g
26dBm @ 6~24Mbps
25dBm @ 36Mbps
23dBm @ 48Mbps
22dBm @ 54Mbps
IEEE 802.11b
27dBm @ 1 ~ 11Mbps
Antenna: Directional Embedded Antenna (Diversity Support); Peak Gain 4dBi

SOFTWARE FEATURES:
Topology: Infrastructure / Ad-Hoc
Operation Mode: Access Point / Universal Repeater / WDS
LAN: DHCP Client
VPN: VPN pass-through (PPTP, L2TP, IPSEC)
Wireless:
Wireless Mode 802.11b / 802.11g / SuperG
Channel Selection (Setting varies by Country)
Transmission Rate 802.11b/g: 108, 54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, 1 in Mbps
Transmit Power Control
Antenna Diversity
Security:
WEP Encryption 64/128/152bits
WPA Personal (WPA-PSK using TKIP or AES)
WPA Enterprise (WPA-EAP using TKIP)
802.1x Authenticator
Hide SSID in Beacons
Multiple SSID with 802.1q VLAN Tagging (up to 4 SSID)(Access Point mode)
MAC Filter
L2 Isolation
Wireless STA (Client) Connected List
QoS: WMM

MANAGEMENT:
Configuration: Web-Based Configuration (HTTP) / Telnet
Firmware Upgrade: Upgrade Firmware via Web Browser; Keep Latest Setting When Firmware Update
Administrator Setting: Administrator Password Change
Reset Setting: Reboot (Press 1 second) / Reset to Factory Default (Press 5 seconds)
System Monitoring: Status, Statistics and Event Log
SNMP: V1, V2c
MIB: MIB I, MIB II (RFC1213) and Private MIB
Backup & Restore: Settings Through Web

ENVIRONMENT & PHYSICAL:
Temperature Range: Operation 0°C to 45°C (32°F to 113°F) / Storage -20°C to 70°C (-4°F to 158°F)
Humidity (Non-condensing): 5%~95% Typical
Dimensions: Diameter: 4.73” (120mm) x Height: 1.97” (50mm)
Weight: 0.62lb. (280g)
