345C Sonar Color Description
The 345c Sonar only # 407660-1 features a brilliant color 320V x 240H 3.5" display with LED backlight and advanced DualBeam PLUS sonar with 2400 Watts PTP power output.

Features:

- Switchfire Sonar
- Split Screen Zoom
- Split Screen Bottom Lock
- Wide Narrow Cone Split Screen
- Instant Image Update
- Selective Fish ID+
- Real Time Sonar RTS Window
- Sonar Echo Enhancement
- TrueArch Technology
- Large Digits View
- Custom View Selections
- Custom Digital Readout Selection
- Selectable Display Colors
- Selectable Background Colors
- Temperature Alarm
- Triplog - Optional
- X-Press™ Menu System

Specifications:

- Display Size: 3.5” Diagonal
- Display Pixel Matrix: 320Vx240H
- Display Type: 256 Color TFT
- Display Colors/Grayscale: 256 Colors
- Dual Beam Plus: 300 kHz 20 degree/83 kHz 60 degrees
- Target Separation: 2.5”
- Power Output (RMS): 300 watts
- Power Output (Peak to Peak): 2400 watts
- Temperature: Included
- Speed: Capable
- Backlight: Yes
- Waterproof: Yes
- Mount: Quick Disconnect
- Unit Size: 5.25”Wx7.4”Hx4”D
- Transducer Standard: XNT-9-20-T
- Transducer Mounting: Inside hull or Transom
- Power Input: 10-20 VDC
- Power Draw: Lights off 380mA
